GenPlanner is a territorial zoning engine for generating spatially consistent territorial zones (and optionally blocks) from polygonal territories.

It combines:

ratio-based functional zoning
adjacency constraints via relation matrices
optional fixed spatial anchors
integration of existing zones
road-based splitting
MILP-based multi-feature allocation
geometric optimization via Voronoi splitting

Quickstart¶

Installation¶

pip install genplanner

Minimal example¶

import geopandas as gpd
from genplanner import GenPlanner
from genplanner.zones import basic_func_zone

territory = gpd.read_file("territory.geojson")

gp = GenPlanner(features_gdf=territory)

zones, roads = gp.features2terr_zones(
    funczone=basic_func_zone
)

Generate blocks¶

blocks, roads = gp.features2terr_zones2blocks(
    funczone=basic_func_zone
)

With relation constraints¶

zones, roads = gp.features2terr_zones(
    relation_matrix="default"
)

With fixed anchor points¶

from shapely.geometry import Point
from genplanner.zones import default_terr_zones

fix_points = gpd.GeoDataFrame(
    {
        "fixed_zone": [default_terr_zones.residential_terr],
        "geometry": [Point(30.1, 59.9)],
    },
    crs=territory.crs,
)

zones, roads = gp.features2terr_zones(
    terr_zones_fix_points=fix_points
)

Design philosophy¶

GenPlanner is built around a small set of composable primitives:

Zoning Primitives define what spatial program should be achieved.
Zone Relations define which zones may or may not be adjacent.
GenPlanner orchestrates preprocessing, validation, optimization and splitting.
Errors define a strict, explicit failure model.

The goal is deterministic, reproducible zoning with clear constraints and explicit spatial control.
